Created floor plans and 3D modelling of an existing building for visualization

Project Objective:

Create a 2D Floor plan and 3D views of the residential unit.

Client Synopsis:

Our customer provided hand-drawn designs to create a 2D floorplan and 3D views of the building.

Challenges Faced:

Measuring the dimensions from hand-made drawings was quite a task. Also, there was no correlation between internal and exterior dimensions, and that made it slightly tedious for our engineers.

Conclusion:

• Besides the flawless final 2D & 3D models. The job was completed on time too as per the client’s specifications.
• We rendered 3D models and visualization that made design and communication approval easy.
• Further, reduce on-site dangers to a minimum and accelerate the project work.
